Specifications

Mounting Type                                             Panel Mount

Reset Method                                               Turn to Release

Normal State Configuration                        2NC

 Cutout Diameter                                          22mm

Supply Current                                             10 (Fuse) A, 6 A @ 120 V ac

Pole and Throw Configuration                     DPST

  IP Rating                                                     DIP66, IP67, IP69, IP69K

Push Button Actuation                                 Push Emergency Stop

 Supply Voltage                                            110v to 600v

  Head Style                                                   Mushroom

Illuminated                                                    No

Range                                                            Harmony

Head Diameter                                             40mm

 Dimensions                                                 40 x 46.5 x 82.5 mm

Colour                                                          Red

Width                                                            82.5mm

Depth                                                            46.5mm

  Housing Material                                      Chromium Plated Metal                                                                                  (Bezel), Zamk (Collar)

Series                                                           Harmony XB4
