Specifications

Housing material                       PA66

Button material                         PC

Contacts material                     Copper with compound silver

Rating                                       3A 6A 10A 15A 250V AC

Temperature                            -40C TO 125C

Dielectric strength                   1500Vrms min

Contact resistance                   <30M OHM

Insulation resistance              >100M OHM

Flammability                           UL94V0

Electric life                              5000 cycles

Mechanical life                       5000 cycles

Reference standard                 EN 61058-1
