240D25 Solid State Relay (SSR)

SPECIFICATION

Made in USA

Contact Form                             SPST-NO

Control Voltage                          6 to 36 VDC

Current Rating                           25 A

Operating voltage Max             280V AC

 Control voltage Min                 3VDC

 Control voltage Max                32VDC

 Newark part NO                      18M9782

Dimensions                               1.75" W x 2.25" H x 0.77" T

Function                                    DC Switching

Mounting Type                          Panel Mount

On State Voltage Drop             1 VAC

Primary Type                            Solid State Relays
